• Specification Code:*

Output: 32KN
Stroke: 40mm
Pressing range:
Φ6.35-Φ100mm(1/4"-4")Copper pipe
Φ12-Φ54mm(1/2"-2")Stainless steel pipe
Φ12-Φ108mm(1/2"-4")PEX‚ Multi-layer composite pipe
Cycle time: 3-6s
Press cycle/charge: 350cycles(DN20)
Standard battery: 18V Li-ion 4.0Ah
Charging time: 80mins
Charger: input AC100-240V 50/60Hz output DC 18/14.4 3A
Working temperature: -10℃～+40℃
Service interval: 40000cycles
Weight: 4.1kgs(tool with battery)‚ 6.2kgs(tool with battery and jaw)
Tool size: 490x89x123mm (without jaw)

Battery:2 pcs
Charger:1 pc
Sealing ring of cylinder: 1 set
Sealing ring of safety valve: 1 set
