• Specification Code:HH-300

Output force:60KN
Stroke:17mm
Crimping range: Cu 300mm²/Al 240mm²
Crimping cycle: 2.5~6s(depends on size of lug)
Hydraulic oil:Shell Tellus T15
Voltage: AC220V 50/60Hz
Rated Power:520W
Package:Plastic box
Product size:432×124×75mm
Accessories:
Crimping dies:16,25,35,50,70,95,120,150,185,240,300mm²
Sealing ring of cylinder:1pc
Sealing ring of safety valve:1pc
