• Specification Code:HH-400

Output force:120KN
Stroke:42mm
Crimping range: Cu 400mm²/Al 300mm²
Crimping cycle: 5~8s(depends on size of lug)
Hydraulic oil:Shell Tellus T15
Voltage: AC220V 50/60Hz
Rated Power:550W
Package:Plastic box
Weight:7.6kgs
Product size:428×134×75mm
Accessories:
Crimping dies:16,25,35,50,70,95,120,150,185,240,300,400mm²
Sealing ring of cylinder:1pc
Sealing ring of safety valve:1pc
