Technical data:
1.Rated output: 605KN(61.8T)
2.Rated pressure: 70Mpa (700 bar)
3.Piston stroke: 35mm
4.Oil capacity: 316ml
5.Retraction mode: Spring retraction (Single action)
Crimping range:
Copper sleeve pipe: ￠60mm
Aluminum sleeve pipe: ￠60mm
Steel sleeve pipe: ￠26mm
In order to meet the demand please provide appropriate size and a standard of tube when place order.
