Working force: 60KN
Stroke: 42mm
Crimping range: Cu 16-300mm2
Al 10-240mm2
Cutting range: ￠40mm for Cu/Al cable and armoured Cu/Al cable
Punching range: ￠22.5-61.5mm fin the 3.5mm mild steel
Length:300mm
Weight:3.5kg
Package: Steel case
Accessories:
Crimping die:16‚25‚35‚50‚75‚95‚120‚150‚185‚240‚300mm2
Punches&die(Type C):22.5‚28.3‚34.6‚43.2‚49.6‚61.5mm
Blade:1pc
Adapter for crimping:1 pc
Adapter for punching:1pc
3/4"‚16UN Draw stud:1pc
7/16"‚20UN Draw stud:1pc
Spacer:1pc
Sealing ring of cylinder:1set
Sealing ring of safety valve:1set
