Crimping force: 60KN
Stroke: 42mm
Crimping range: Cu 16-300mm2
Al 10-240mm2
Cutting range: 40mm for Cu/Al cable and amoured Cu/Al cable.
Punching range: ￠22.5-61.5mm in the 3.5mm mild steel
Length:540mm
Weight:3.5kg
Package:steel case
ACCESSORES:
Crimping dies:16‚25‚35‚50‚70‚95‚120‚150‚185‚240‚300mm2
Punches&die(Type C):22.5‚28.3‚34.6‚43.2‚49.6‚61.5mm
Blade: 1 set
Adapter for crimping: 1pc
Adapter for punching: 1 pc
3/4"‚16UN Draw stud:1 pc
7/16"‚20UN Draw stud:1 pc
Spacer: 1 pc
Sealing ring of cylinder: 1 set
Sealing ring of safety valve: 1 set
