Rated clamping force:≥32KN
Rated working pressure:52Mpa
Piston stroke:40mm
Clamping range:
Clamp die specification for thin-wall stainless steel pipe‚ copper pipe ( nominal OD):
15‚18‚22‚28‚32‚42‚54
NOTE: 15‚18‚22‚28 is for hexagon clamping; 32 is for quincunx clamping; 42‚54 is for 3-pieces chain clamping.
Clamp die specification for XPAP:
TH type: 16‚20‚26‚32
U type: 16‚20‚25‚32
Clamp die specification for PEX:
15(3/8")‚ 18(1/2")‚ 20(5/8")‚ 24(3/4")‚ 30(1")
NOTE: In order to meet demand please provide appropriate size and a standard of tube when place order.
Working temperature: -10℃～40℃.
